Steel for Boilers and Pressure Vessels A516 gr.60
A516 gr.60 steel plate has good toughness and low effectiveness of the tendency in the use of bending, curling, deformation processing such as cold, after more prolonged storage and use remains a good toughness, A516gr.60 steel plate also has good weldability and resistance to intergranular corrosion. For the manufacture of boiler drum, beams and wall panels.
A516 gr.60 Steel Plate specification:
Thickness: 6MM to 300MM,
Width: 1500mm to 4050mm,
Length: 3000mm to 15000mm
Steel Adopt Standard: ASTM A516
Composition |
Percentage % |
Composition |
Percentage % |
|
C |
0.18 |
Cu |
0.3 |
|
Si |
0.4 |
Ni |
0.3 |
|
Mn |
0.95/1.50 |
Mo |
0.08 |
|
P |
0.015 |
Nb |
0.01 |
|
S |
0.008 |
Ti |
0.03 |
|
Al |
0.02 (Min) |
V |
0.02 |
|
Cr |
0.3 |
- |
- |
A516 gr.60 Steel Chemical Composition:
A516 gr.60 Steel Mechanical Property:
Grade |
Thickness |
Yield |
Tensile |
Elongation |
|
A516 grade 60 |
mm |
Min Mpa |
Mpa |
Min % |
|
6-40 |
220 |
415-550 |
25% |
|
|
40-100 |
220 |
415-550 |
21% |
Equivalent Specifications and Standards of A516 gr.60 Steel
Standard |
Description |
|
ASTM/ASME |
A/SA516 - Grade 60 |
|
DIN Standard |
DIN 17155 HII |
|
British Standard |
BS1501-161-430A |
|
European Norm |
EN10028 P265GH |
If you have any questions about A516 gr.60 Steel technique data and A516 gr.60 Steel price, please feel free to contact us.
