S460ML Structure steel plate Material Heat Treatment

S460ML Structure steel plate Material Heat Treatment

S460ML Structure steel plate,S means the structural steel, M means the delivery condition. Capital letter L for the quality with specified minimum values of values of impact energy at temperature not lower than -50 degree. S460ML steel Grade is a technical delivery conditions for thermo mechanical rolled weldable fine grain structural steels.

S460ML steel plate is in steel standard EN 10025-4.S460ML steel shall be suitable for welding,and general requirements for arc welding of the steel S460ML shall be given in EN 1011-2.S460ML steel plate is also suitability for hot-dip zinc-coating,this requirements shall be agreed between manufacturer and purchaser.

S460ML Structure steel plate Specification

Thickness: 6mm-350mm

Width: 1500mm-4200mm

Length: 3000mm-18000mm

S460ML Structure steel plate Chemical compostion(%)

C≤0.18 Si≤0.65 Mn≤1.80 P≤0.030 S≤0.025 Nb≤0.06 V≤0.14 Al≥0.015 Ti≤0.06 Cr≤0.35 Ni≤0.85 Mo≤0.23 Cu≤0.60 N≤0.027

S460ML Structure steel plate Mechanical properties

Yield strength Mpa:385-460 Tensile strength Mpa:490-720 Elongation(%):17 Impact Energy(KV J)Min:-50degree,27

Heat Treatment: Thermo-Mechanical Control Process (TMCP)

Additional requirements:

UT: EN 10160-S3E3/S3E4, SEL 072-Ⅰ; JIS G 0801, EN10160-S2E2/S2E3, SEL 072-Ⅱ, A578 Level C; SEL 072-Ⅲ/Ⅳ, EN10160-S1E1/S0E1, A578 Level B; A578 Level A, A435.

Z test: Z15, Z25, Z35

Bebon international major exporting countries in Europe, America, Southeast Asia, the Middle East, South America, Africa, and other countries. We offer excellent quality and competitive prices of S460ML Structure steel plate. If you believe in our S460ML Structure steel plate, pls contact us in any time.
