P265GH steel plate National Standard

P265GH steel plate is a weldable non-alloy quality pressure vessel steel. P265GH steel plate has a wide application in the manufacture of pressure vessels, boilers and heat exchangers in the oil and gas industry. P265GH steel plate is also used in chemical and pharmaceutical process plants.

P265GH steel plate Chemical composition(%)

Grade	C. %	Mn.%	S.	N	Cu	Nb	Ti.	Si.	P.	AL	Cr.	Mo.	Ni	Vi
P265GH	0.20	0.80-1.40	0.015	0.012	0.30	0.020	0.03	0.40	0.025	0.020	0.30	0.08	0.30	0.02

P265GH steel plate Mechanical properties

Grade	Type	Thickness mm	Yield strength Mpa(min)	Tensile Strength MPa	Elongation % (min)	Impact Energy (KVJ) (min)
Grade	Type	Thickness mm	Yield strength Mpa(min)	Tensile Strength MPa	Elongation % (min)	-20°	0°	+20
P265GH	Normalized	≤16 16>to≤40 40>to≤60 60>to≤100 100>to≤150 150>to≤250	265	410-530	22	27	34	40
			255	410-530	22	27	34	40
			245	410-530	22	27	34	40
			215	410-530	22	27	34	40
			200	400-530	22	27	34	40
			185	390-530	22	27	34	40

BBN Steel have our own processing factory for P265GH steel plate, can offer client the service like wire drawing, Grinding mirror,cutting, knurling.If you are interest in the P265GH steel plate,I’m looking forward to your enquiry.
