ASTM A387M Gr11CL1 steel plate Yield strength
ASTM A387M Gr11CL1 steel plate Yield strength
The equal ASTM A387M Gr11CL1 steel plate is under American steel stamdard SA 387/SA 387M. ASTM A387M Gr11CL1 steel plate intended primarily for welded boilers and pressure vessels&tanks.
ASTM A387M Gr11CL1 steel plate is widely used in the fabrication of boilers and pressure vessel,such as chemical gas industry project. ASTM A387M Gr11CL1 steel plate is applicable for welding boiler and pressure vessel with chromium molybdenum alloy plates working under high temperature.
ASTM A387M Gr11CL1 steel plate Chemical composition(%)
|
Grade |
The Element Max (%) |
||||||
|
C |
Si |
Mn |
P |
S |
Cr |
Mo |
|
|
A387 Gr.11 Cl.1 |
0.04-0.17 |
0.44-0.86 |
0.35-0.73 |
0.035 |
0.035 |
0.94-1.56 |
0.40-0.70 |
Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%
ASTM A387M Gr11CL1 steel plate Mechanical properties
|
Grade |
A387 Gr.11 CL.1Mechanical Property |
|||
|
Thickness |
Yield |
Tensile |
Elongation |
|
|
A387 Gr.11 Cl.1 |
mm |
Min Mpa |
Mpa |
Min % |
|
t≦50 |
240 |
415-585 |
22 |
|
|
50<t≦200 |
240 |
415-585 |
19 |
|
